Nitrox 10 kW Hybrid Inverter – High-Performance Solar & Backup Solution

Insert Material: PPO Contact Material: Solid Pin, Copper, Tin Plated Rated Current: 5A Rated Voltage: 1000V(TUV) 600V(UL) Test Voltage: 8KV(TUV50HZ, 1min) Contact Resistance: <0.5mΩ Degree of Protection: IP67 Working Temperature: -40°C to 85°C Flammability Rating: UL 94-V0 Safety Class: Ⅱ

The Huawei SUN2000-115KTL-M2 is a high-performance 115kW three-phase solar inverter engineered for large-scale commercial solar systems, industrial PV projects, and utility-scale solar installations. Part of the advanced Huawei FusionSolar portfolio, this grid-tied solar inverter delivers industry-leading efficiency, intelligent monitoring, and enhanced safety features for reliable long-term solar power generation.

With a maximum efficiency of 98.8% (@480V), this Huawei commercial solar inverter maximizes DC-to-AC conversion, ensuring higher energy yield and improved ROI for businesses. Its compact design (1035mm × 700mm × 365mm) and 93 kg weight allow easier installation and seamless integration into commercial rooftops and solar plants.

Designed for demanding environments, the inverter features dual DC inputs, residual current protection, DC & AC surge arresters, and fuse-free architecture, reducing maintenance costs while improving operational safety. The integrated string-level monitoring and Smart I-V Curve Diagnosis enable real-time performance tracking and faster fault detection. With MBUS communication support, system monitoring and control become more efficient for EPC contractors and plant operators.

The IP66-rated enclosure ensures protection against dust, water, and harsh weather conditions, making it ideal for industrial solar installations in Pakistan and other challenging climates.

---

Key Specifications

• Model: SUN2000-115KTL-M2

• Capacity: 115kW

• Type: Three Phase Grid-Tied Solar Inverter

• Max Efficiency: 98.8% (@480V)

• Dimensions: 1035mm × 700mm × 365mm

• Weight: 93 kg

• Protection Rating: IP66

• DC Inputs: Dual

• Safety Features: Residual current protection, DC/AC surge arresters

• Monitoring: String-level management, Smart I-V Curve Diagnosis, MBUS

For the latest Huawei Solar Inverter Prices in Pakistan, contact Apower Engineering & Services

The Fox ESS U-Series 36 kW inverter delivers powerful, efficient, and smart solar energy conversion for larger residential rooftops, commercial buildings, and industrial PV systems. Designed for dependable grid-tied performance, this three-phase inverter ensures your solar investment works hard every day. With high conversion efficiency up to ~98.3%, it helps maximize usable solar power and return on investment, while its wide input voltage range and low start-up threshold allow power generation even in low-light conditions, extending the daily energy production window.

Advanced MPPT & Smart Optimization

Equipped with multiple independent MPPT trackers, the U-Series intelligently optimizes power extraction from different solar panel strings, making it ideal for systems with multiple orientations or partial shading. Users can monitor production and system performance in real-time via the FoxCloud app or web portal, receiving alerts and tracking performance trends from anywhere.

Built to Withstand Harsh Environments

The IP66-rated rugged housing protects the inverter against dust, rain, and extreme weather, suitable for both indoor and outdoor installations. Its natural cooling design reduces noise and maintenance needs, while built-in safety protections such as anti-islanding and surge safeguards ensure long-term reliability for industrial and commercial solar systems.

⚡ Ideal For
✔ Large residential rooftops
✔ Commercial solar buildings
✔ Industrial PV systems
✔ Grid-tied and net-metering applications

For the latest Solar Inverter Prices in Pakistan, contact Apower Engineering & Services today to get the best market rates on FoxESS Inverter in Pakistan.

Galvanized Structure L2 96" & L3 143" (14 Gauge) with MS & SS Nutt Bolts & Rawal bolts.
