• 7800 WATTS MPPT SUPPORTS UP TO 600 WATTS SOLAR PANEL
• 140 AMP Solar charger
• Smart Pv Monitoring Platform
• Stick logger
• Max. Efficiency 97.6%
• Support Multiple Parallel
• Zero Export
• RS485 / CAN
• Efficiency
• IP65 Ingress Protection
• Support Generator Connection
• High Surge Endurance
• High Power Factor
• Touch Screen Display
• MPPT
• Internal SPD
• Six-Time of Use Setting
• Safe

The Huawei SUN2000-115KTL-M2 is a high-performance 115kW three-phase solar inverter engineered for large-scale commercial solar systems, industrial PV projects, and utility-scale solar installations. Part of the advanced Huawei FusionSolar portfolio, this grid-tied solar inverter delivers industry-leading efficiency, intelligent monitoring, and enhanced safety features for reliable long-term solar power generation.

With a maximum efficiency of 98.8% (@480V), this Huawei commercial solar inverter maximizes DC-to-AC conversion, ensuring higher energy yield and improved ROI for businesses. Its compact design (1035mm × 700mm × 365mm) and 93 kg weight allow easier installation and seamless integration into commercial rooftops and solar plants.

Designed for demanding environments, the inverter features dual DC inputs, residual current protection, DC & AC surge arresters, and fuse-free architecture, reducing maintenance costs while improving operational safety. The integrated string-level monitoring and Smart I-V Curve Diagnosis enable real-time performance tracking and faster fault detection. With MBUS communication support, system monitoring and control become more efficient for EPC contractors and plant operators.

The IP66-rated enclosure ensures protection against dust, water, and harsh weather conditions, making it ideal for industrial solar installations in Pakistan and other challenging climates.

---

Key Specifications

• Model: SUN2000-115KTL-M2

• Capacity: 115kW

• Type: Three Phase Grid-Tied Solar Inverter

• Max Efficiency: 98.8% (@480V)

• Dimensions: 1035mm × 700mm × 365mm

• Weight: 93 kg

• Protection Rating: IP66

• DC Inputs: Dual

• Safety Features: Residual current protection, DC/AC surge arresters

• Monitoring: String-level management, Smart I-V Curve Diagnosis, MBUS

For the latest Huawei Solar Inverter Prices in Pakistan, contact Apower Engineering & Services

The Fox ESS R-Series brings powerful and efficient three-phase grid-tied inverters for commercial and industrial solar systems. Designed for maximum energy harvesting, high reliability, and smart operation, this range offers the ideal solution for large solar installations, rooftops, factories, warehouses, commercial solar farms, and net-metering projects. The R-Series inverters convert DC power from solar panels into clean AC electricity for the utility grid, providing high efficiency up to ~98.6%, robust protection, and flexible system configuration. With a wide MPPT voltage range and multiple independent MPPT trackers, these inverters ensure optimized solar energy harvesting and longer generation windows for improved performance.

Available Models

• Fox ESS R‑Series 100Kw Three Phase On‑Grid  Inverters
• Fox ESS R‑Series 110Kw Three Phase On‑Grid  Inverters
• Fox ESS R‑Series 125Kw Three Phase On‑Grid  Inverters

🔌 Key Specifications & Features

High Performance & Efficiency

• Max Efficiency: ~98.6%

• European Efficiency: ~98.2%

• Wide MPPT voltage range for better energy capture

• Multiple independent MPPT trackers for optimized solar harvesting

Advanced Input & Output

• Max DC Input Voltage: 1100 V

• Start-Up Voltage: ~250 V

• Rated DC Voltage: 600 V

• Adjustable power factor: 0.8 leading to 0.8 lagging to match grid requirements

• Supports standard three-phase grid voltage ranges (320 V–460 V)

⚡ Ideal For
✔ Large rooftops and factories
✔ Commercial solar farms
✔ Industrial solar installations
✔ Net-metering & grid-tied projects

💰 For genuine Fox ESS R-Series inverters, commercial solar solutions, and complete backup support in Pakistan, contact Apower Engineering & Services today for the best market rates and local expert support.

Insert Material: PPO Contact Material: Solid Pin, Copper, Tin Plated Rated Current: 5A Rated Voltage: 1000V(TUV) 600V(UL) Test Voltage: 8KV(TUV50HZ, 1min) Contact Resistance: <0.5mΩ Degree of Protection: IP67 Working Temperature: -40°C to 85°C Flammability Rating: UL 94-V0 Safety Class: Ⅱ
